HeyGears UltraCraft Reflex 3D Printer + Wash and Cure Kit
£2,399.00 (incl. VAT)
The UltraCraft Reflex 3D Printer + Wash and Cure Kit Bundle offers you an efficient and powerful combo of a resin printer and a compact system for efficient cleaning and curing of your prints. The dual-frequency UV technology ensures optimal curing of your models, while the cleaning unit guarantees thorough removal of excess resin. A complete system for detailed prints where quality and efficiency are the focus – perfect for professional demands and ambitious projects.
UltraCraft Reflex 3D Printer + Wash and Cure Kit
The HeyGears UltraCraft Reflex resin printer offers a complete solution for precise manufacturing. With an impressive 33 μm XY resolution and intelligent printing strategies, it delivers consistent, high-quality results. The smart assistance system optimises the printing process, while high-performance materials enable printing for demanding applications. This printer is focused on efficiency and quality, making it ideal for professional applications.
UltraCraft Wash from HeyGears
- Fast washing processes
- Vibration-based cleaning
- Easy reuse of cleaning agents
UltraCraft Cure from HeyGears
- Dual-mode curing
- 360° uniform curing
- Final curing with two UV wavelengths
- Automatic parameter adjustment
What are the Benefits?
- TrueUV light source: Uses a variable UV wavelength that automatically adjusts to the specific resin materials to produce improved end results. With a cross-linking rate of over 60%, polymerisation is optimised, significantly increasing material performance.
- Hardware Deluxe: The UltraCraft Reflex features a perforated steel build platform for longer life and better adhesion. With an industrial-grade Z-axis ball screw, the printer achieves a positioning accuracy of ±2 μm and guarantees precise, low-friction movements. The durable release film lasts over 45,000 print layers and can be easily replaced if necessary. The resin printer features a 6K monochrome screen measuring 192 x 121 mm and with a resolution of 5760 x 3600 px. The printer uses a COB light source with a freeform lens that provides light uniformity of over 94% and a draft angle of less than 2°.
- Automatic resin refill system & heated tray: The printer is equipped with an automatic resin refill system and a heated resin tray. The clever system recognises the resin type, monitors the fill level and automatically refills the material when necessary. In addition, the optimal printing temperature is kept constant to ensure the best printing results.
- Equipped with 3 intelligent algorithms: 3D Anti-Aliasing Smoothes image edges and layers for a finer texture. WDR Fusion+ Adjusts the exposure of multiple layers to create sharper surfaces. PICK Intelligent Recognition Separates the model from the supports during exposure, making support removal easier and improving surface quality.
- Excellent quality – always and everywhere: The UltraCraft Reflex ensures consistent printing results thanks to a light uniformity calibration system and precise control of the curing energy (within ±1%). This ensures consistent print quality even over long periods of time.
Additional Features
- Real-time Peeling Force Management, where the peeling force is automatically adjusted with each print (prevents parts from falling off, minimises part breakage during printing, fewer visible surface layers),
- Intelligent workflows enable pleasant use for both beginners and professionals,
- Automatic levelling and precise auto-zeroing,
- Release Film Lifespan Monitoring notifies you when it is time to replace the film,
- Constantly monitors the printing status and informs about possible errors.
